Foxpower CCTV Rugged Uninterruptible Power Supply – UPS Modules – FCC 650, FCC 1000, FCC 1500, FCC 2000
The Foxpower FCC uninterruptible power supply (UPS) modules provide clean, reliable power control and management as part of a complete UPS solution. The FCC is a line of rugged UPS power modules used worldwide in the most demanding environments where clean backup power is needed. Designed to perform in the most extreme demanding environments, Foxpower FCC units ensure equipment in security, communications, traffic, industrial environments, and many other critical applications remain safe and protected from power disturbances. The Automatic Voltage Regulator (AVR) offers power stability, reliability, and certainty during unpredictable environmental states and creates voltage equilibrium during varied power conditions. As well, the Foxpower FCC series of power modules are designed to instantly switch to emergency backup power during any utility power failures or interruptions. Thanks to its powerful programmable battery charger, the FCC is capable of providing the runtime you need. All FCC models are available in 120Vac and 230Vac.
Product Highlights
- Full featured, ruggedized UPS provides clean, uninterruptible backup power ensuring your system will remain running during power outages
- Wide range Automatic Voltage Regulation (AVR) without going to batteries lengthens battery life, even during periods of surge or sag in the line voltage
- External communications via RS-232 port or (optional) Ethernet SNMP interface provides local or remote monitoring and control
- Independently programmable and dry contact relays allow tracking and controlling of key functions
- Event and alarm logging with time and date stamping simplifies and accelerates troubleshooting
- A wide operating temperature range of -40 to 74°C (-40 to 165°F) is suitable for the most extreme operating environments
- Temperature compensated battery charging protects batteries from over charging at extreme temperatures, extending the life of the battery
- White text on blue display improves readability in bright daylight
- Automatic frequency sensing (60Hz/50Hz)
- Variable speed fan with fan failure alarm
- Circuit breaker protection on the input and external battery input
- Three mounting configurations: wall, shelf and rack (rack mount kit required)
- Generator-ready for extended runtime option
- Three user inputs: self test, alarm, shutdown
- User adjustable charger: off, 3A, 6A, 10A
Technical Specification
| Model | FCC 650 | FCC 650E | FCC 1000 | FCC 1000E | FCC 1500E | FCC 2000 | FCC 2000E |
|---|---|---|---|---|---|---|---|
| Nominal voltage | 120Vac | 230Vac | 120Vac | 230Vac | 230Vac | 120Vac | 230Vac |
| Input voltage range | 85 to 175Vac | 150 to 328Vac | 85 to 175Vac | 150 to 328Vac | 150 to 328Vac | 85 to 150Vac | 150 to 328Vac |
| Output voltage regulation | ±10%over full input voltage range | ||||||
| Output voltage waveform | Pure Sine Wave | ||||||
| Typical efficiency | >98% (with full resistive load) | ||||||
| Typical output voltage THD | <3% | <3% | <3% | <3% | <3% | <3% | <3% |
| Typical transfer time | <5ms | <5ms | <5ms | <5ms | <5ms | <5ms | <5ms |
| Nominal frequency | 60Hz | 50Hz | 60Hz | 50Hz | 50Hz | 60Hz | 50Hz |
| Input current | 8A | 4.5A | 16A | 8A | 12A | 20A | 12A |
| Output current | 5.4A | 2.8A | 9.1A | 4.78A | 8.69A | 16.6A | 8.69A |
| Ouput power @ 50°C | 650W/VA | 650W/VA | 1000W/VA | 1000W/VA | 1500W/VA | 2000W/VA | 2000W/VA |
| Ouput power @ 74°C | 500W/VA | 500W/VA | 800W/VA | 800W/VA | 1000W/VA | 1500W/VA | 1500W/VA |
| Battery string voltage | 24/48Vdc | 24/48Vdc | 24/48Vdc | 24/48Vdc | 48Vdc | 48Vc | 48Vdc |
| Audible noise @1m | 45dBA | 45dBA | 45dBA | 45dBA | 45dBA | 45dBA | 45dBA |
| Width (mm/in) | 432/17 | 432/17 | 394/15.5 | 394/15.5 | 394/15.5 | 394/15.5 | 394/15.5 |
| Height (mm/in) | 88/3.47 | 88/3.47 | 133/5.22 | 133/5.22 | 133/5.22 | 133/5.22 | 133/5.22 |
| Depth (mm/in) | 229/9 | 229/9 | 222/8.75 | 222/8.75 | 222/8.75 | 222/8.75 | 222/8.75 |
| unit weight (kg/lb) | 11/25 | 11/25 | 16/35 | 16/35 | 16/35 | 16/35 | 16/35 |
| Operating temperature | -40°C to 74°C (-40°C to 165°F) | ||||||
| Storage temperature | -40°C to 74°C (-40°C to 165°F) | ||||||
| Operating altitude | 3658m/12,000ft | ||||||
| Operating humidity | up to 95% | ||||||
| Abency Compliance | Eletrical safety North America: UL1778, CSA 22.2 No 107.3 Electricl safety International: CE EN62040-1-2 EMI compliance: FCC/IC/CE Class A; CISPR 22/ EN50022; EN 62040-2 |
||||||
